As a new arrival of AGFrc mini servos, A20BHS can reach the torque of 10.4kg and 0.055sec fast speed. Full CNC aluminium case to provide the good heat dissipation conditions, featuring a digital programmable circuit high voltage compatible. The biggest special about this new digital programmable servo A20BHS is that it used a newly designed brushless motor, which AGFrc first released and marketed. With the more efficient brushless motor and high accuracy, this high-performance servo A20BHS is perfect for RC cars and other applications.
Feature
High Performance Programmable Mini Servo
Longer Lifespan Brushless Motor
Full CNC Aluminium Housing
Sturdy Metal Double Ball Bearings
Special Small Size Design
High-Voltage Capable
Ideal for 1/24 scale RC Monster Car, Crawler Car, SCX10.3, SCX24, Racing Car, RC Airplane etc.
Specification
Item: A20BHS
Operating Voltage: 4.8-8.4V
Operating speed: 0.085sec/ 60° @ 4.8V
Operating speed: 0.075sec/60° @ 6.0V
Operating speed: 0.062sec/60° @ 7.4V
Operating speed: 0.055sec/60° @ 8.4V
Stall Torque: 6.50 kg-cm (90 oz-in) @ 4.8V
Stall Torque: 7.80 kg-cm (108 oz-in) @ 6.0V
Stall Torque: 9.20 kg-cm (127 oz-in) @ 7.4V
Stall Torque: 10.40 kg-cm (144 oz-in) @ 8.4V
Gear: Strength Steel + Copper
Motor：Brushless
Size: 23*12*27.5mm (0.90 x 0.47 x 1.08 in)
Weight: 21g
Connector Wire: TYU 180mm / 26AWG
